Specifications:
| Model | MK600 |
| Product Type | WiFi Router |
| Form Factor | 4G CPE |
| Color | White |
| Adapter | EU Plug/US Plug |
| Size | 190 x 120 x 30mm (L * W * H) |
| Weight | about 240g |
| Hardware Configuration | |
| Receive Diversity | Support |
MIMO | Support DL 2×2 MIMO |
BB Chipset | 7100CE |
WiFi Chipset | MT7628NN |
WiFi Users | 32 |
Product Antenna | 128MB ROM 256MB RAM |
Ethernet | 1 * WAN Ports 3 * LAN Ports |
System Reset Button | 1 |
SIM Card Slot | 1 |
Power Input Interface | 1 |
Power Consumption | <10W |
| Power Voltage | DC12V/1A |
| ESD | Contact±8KV、Air±10KV |
| LED | Power Indication LED System Status LED Wi-Fi Indication LED LAN Indication LED*4 Signal Strength LED 4G/WAN Indication LED |
| USIM/SIM | 2FF SIM Card support SIM/USIM/UIM, standard 6 PIN SIM card interface, support 3V SIM card and 1.8V SIM card; internal push-push SIM slot |
Protocol Standard | Wi-Fi 802.11g, Wi-Fi 802.11b, Wi-Fi 802.11n |
| Encryption Type | WPA2-PSK, WPA-PSK |
Software Parameters | |
SW Update | TR069 & FOTA (customized) & Local |
WIFI Mode | AP/STATION Mode |
WIFI Security | OPEN & WPA-PSK & WPA2-PSK |
| UPnP | Customized |
| Voice | VoLTE & CS Domain Voice |
| Firewall | Mac/IP Address Filter, Port Forwarding, WiFi Black/White List |
| IPv4 | Support |
| IPv6 | Support |
| Data Statistics | Support |
| SIM Lock | Support |
| HTTP | Support |
| DMZ | Support |
| Air Interface | |
Technical Standard | Compatible with WCDMA, FDD-LTE, TDD-LTE Default 802.11b/g/n |
Frequency | LTE: B1/3/5/7/8/20/38/40/41 WCDMA: B1/5/8 (customizable frequency band) |
| WIFI | 2.4G, WIFI 2*2 MIMO, 802.11 b/g/n |
Maximum Data Throughput | LTE CAT 4 FDD-LTE(DL/UL) 150Mbps/50Mbps HSPA+ (DL/UL) 21/5.76Mbps |
Work Environment | |
Working Temperature | Normal: -10°C ~ +65°C |
Storage Temperature | -20°C ~+85°C |
Humidity | 5%~95%RH (non-condensing) |
Feature:
◆ MK600 300Mbps 4G LTE Signal Amplifier Router.
◆ Minipcie interface and SIM card slot are provided to support the expansion of built-in 3G/4G applications.
◆ Support LAN or WAN network ports to meet the application requirements of different customers.
◆ Provide system led, Wi-Fi led, Ethernet led, 4G signal status, and network status LED indication.
◆ 4 external antennas provide stable wireless connections and optimal coverage.
◆ Easy setup and enjoy a security wireless network in a minute.
Package Included:
1 x MK600 Wireless Router
1 x Cable
1 x DC 12V/1A Power Adapter (EU/US Plug)
1 x User Manual
